Types of Shackles and Their Applications: A Complete Guide

Shackles are a fundamental component in lifting, rigging, and recovery systems. Acting as the primary connector between chains, ropes, straps, and load points, shackles are everywhere from construction sites and shipyards to off-road recoveries and theatrical rigs. But not all shackles are created equal. With different shapes, pins, materials, and manufacturing methods, each type is designed for a specific purpose and environment.

Before diving into the types of shackles available, let's go over the basic anatomy of a shackle. Understanding the parts of a shackle is crucial to selecting and using the right one for your application. These components work together to form a strong, reliable connection point for various rigging applications.

Terminology and Parts of a Lifting Shackle | Anatomy of a Recovery Shackle

Key Shackle Terms:

  • Body (Bow): Commonly called the "bail," this is the main curved body of the shackle that connects the two legs or "ears" and forms the primary loop. It's the load-bearing section designed to receive a hook, rope, chain, or sling during lifting or rigging. The body may be shaped as a bow (rounded), a D (straighter) or B (multi-crown) to suit different load directions.
  • Ears: Often referred to as the "legs," these are the ends of the shackle body where the pin is inserted and must align accurately to ensure a secure connection.
  • Pin: The removable bar or fastener that spans the shackle’s opening (or “jaw”), securing the load by closing the connection. It bears both shear and tension forces and may come in the form of a screw pin, round pin, or a bolt with nut and cotter.
  • Crown: The outermost curved part of the body opposite the pin, typically under the most bending stress.
  • Shoulder: The part of the pin head that seats against the ear, controlling how deep the threads engage and ensuring a secure fit.
  • Pin Head: Found on lifting and recovery shackles with screw, round, or bolt-type pins, the pin head allows tool-assisted tightening and secures the connection—screw pins for quick use, round pins for light-duty alignment, and bolt-type pins for permanent or heavy-duty applications.
  • Pin Head Hole: Often referred to as a wrench or spanner hole designed to accept a spud wrench, bar, or pin-type tool to help tighten or loosen the screw pin beyond what can be achieved by hand. This hole is also used for securing the pin in place, typically with safety wire, or mousing wire and in off-roading sometimes zip ties, to prevent the pin from loosening or backing out during use.
  • Eye or Eyelet: Often referred to as a cross-hole, this is a small hole or groove at the end of a bolt-type or round pin used to secure it with a cotter pin, split pin or wire.
  • Threaded End: The part of the pin that screws into one of the ears on screw or bolt-type shackles.
  • Jaw: The open end of the shackle between the two ears where the pin is inserted.
  • Jaw Width (Inside Width): The internal distance between the ears. This measurement determines whether the shackle will fit around the hardware you're connecting to—like tow points, lifting lugs, or sling eyes.
  • Bearing Surface: The interior curve of the shackle body where rigging components such as slings, rope eyes, soft shackles and hardware rest. A larger bearing surface reduces wear.

Understanding the differences isn't just helpful—it's critical to working safely and effectively. Below is a detailed breakdown of the most common types of shackles, their best use cases, and what goes into making these rugged connectors.

Anchor Shackles (Bow Shackles)

Bow Shackle

Anchor shackles, often called bow shackles, feature a wide, rounded body that allows for multi-directional loading. The bow shape helps reduce stress on slings and makes them ideal for applications where the rigging might shift or pull from different angles—like vehicle recovery, lifting multi-leg slings, or marine towing. Their versatility makes them a go-to shackle for general rigging, though they tend to be slightly larger and heavier than more specialized options. In the off-road world, this type of shackle is often mistakenly referred to as a “D-ring,” but that’s technically incorrect. D-rings are a different, narrower type of shackle more accurately described as chain or straight shackles.

This makes anchor shackles particularly well-suited for off-road recovery scenarios where pull angles are unpredictable—such as when extracting a stuck vehicle from mud, sand, or uneven terrain. The wider bow accommodates thicker recovery straps and synthetic ropes, and the ability to handle side loads better than chain shackles adds an extra layer of safety. Their rugged construction and ease of use make them a staple in many 4x4 and overlanding recovery kits.

Screw Pin Shackles

Screw Pin Anchor Shackle

Screw pin shackles are defined by their ease of use. The pin can be quickly removed and installed by hand, making them ideal for temporary connections or jobs that require frequent assembly and disassembly. You’ll find these in recovery kits, construction sites, and utility work. However, in environments with vibration or dynamic loading, the screw pin can back out unless secured properly, so regular inspection is essential.

For off-roaders, screw pin shackles are favored because their pins can be loosened with simple tools (like a spud wrench) and then removed by hand, allowing relatively quick connection and disconnection in tough conditions. This balance between tool-assisted loosening and hand removal makes them practical for recovery scenarios where speed and reliability matter. However, because the pin can loosen under vibration, it’s important to regularly inspect and properly secure them before use.

Bolt-Type Shackles

Bolt style shackle

Bolt-type shackles are designed for permanent or semi-permanent applications where safety is critical. These shackles use a threaded pin secured by a nut and cotter pin to prevent accidental loosening. You’ll find them in lifting operations involving cranes, structural rigging, and environments subject to movement or vibration. While they take longer to install, the added security makes them the preferred choice for long-term use.

For off-road recovery, bolt-type shackles offer a high level of security, especially in situations involving prolonged vibration or dynamic loads—like long trail rides or winch pulls on uneven terrain. Their nut-and-cotter design virtually eliminates the risk of the pin backing out, which can be a concern with screw pin shackles under repeated jolts or movement. However, this added security comes at the cost of convenience. Bolt-type shackles take more time to install and remove, and require tools to do so—making them less practical for quick, on-the-fly recoveries. They're best suited for setups where the shackle stays in place for the duration of the trip, like mounting to a bumper or recovery point.

Round Pin Shackles

Round Pin Shackle

Round pin shackles use a smooth pin secured by a cotter pin rather than threads. They’re often used in tie-down or towing applications where the load is static and not subject to rotation. Because the pin isn't threaded into the body, they’re not recommended for overhead lifting or any application where the pin could experience axial force. That said, they are quick to assemble and often favored in farm, trailer, and transport work.

Round pin shackles are generally not ideal for off-roading or vehicle recovery due to their limited resistance to side loading and dynamic forces. In recovery situations, forces can shift unpredictably, especially during angled pulls or when vehicles are stuck off-camber. Since the smooth pin is only retained by a cotter pin and not threaded into the body, it lacks the rigidity and strength needed for off-angle or shock-loaded scenarios. Using round pin shackles in side loading conditions can lead to pin deformation or failure. For off-road applications where loads are rarely perfectly in-line, a screw pin or bolt-type shackle is a much safer and more reliable choice.

Chain Shackles (D Shackles)

D-Ring Screw Pin Chain Shackle

Chain shackles, or D shackles, have a narrow, U-shaped profile best suited for straight-line pulls. These are true D-Rings because of their true letter "D" shape. The compact shape gives them superior strength when loaded in line, but they’re not built to handle side loads. These shackles are common in hoisting, rigging with single slings or chains, and connecting to eye bolts or lifting lugs where the force is predictable and aligned.

In off-road recovery, the main advantage of chain shackles is their high strength when used in straight-line pulls, such as towing on flat ground or winching from a direct angle. Their compact shape makes them easy to store in tight recovery kits or mount on bumper tabs with limited space. However, a major drawback is their poor performance under side loading—a common occurrence in off-road scenarios where recovery angles are rarely ideal. Using a D shackle at an angle can lead to deformation, reduced load capacity, or even failure, making them less forgiving than bow-type shackles in dynamic recovery situations.

B-Ring Shackles

B-Ring Bridle Shackle

B-Ring shackles, named for their letter "B" shape, also known as bridle shackles, are purpose-built for applications requiring multiple connection points—such as Y-straps or equalized bridles in off-road recovery. What sets them apart is the design of the body: the crown and bearing surface form two distinct sections. The wide, flat bearing surface provides ample space for attaching soft rigging like straps or ropes without bunching, while the separate rounded crown helps distribute force more evenly and maintain proper orientation under load. This separation helps prevent side loading and twisting, making B-Ring shackles especially useful for balanced, stable recoveries where two lines must join at a central anchor point. And yes, they look like testicles and are a great functional replacement for the widely banned Truck Nuts or Bull Balls so you can still hang your masculinity from the back bumper of your rig.

Split Shackles

Split Shackle

Split shackles are a specialized type of shackle commonly used in vehicle recovery, towing, and other load-securing applications where speed and accessibility are critical. Unlike traditional closed-body shackles, a split shackle™ is made of two interlocking hooked arms that pivot to form the shape of a standard anchor (bow) shackle when closed.

The key advantage of a split shackle is its quick-access design. Instead of threading a pin through a solid jaw, the two sides swing open like a pair of jaws, allowing for fast and easy connection to recovery points, tow straps, ropes or chains—especially in muddy, cold, dark, or time-sensitive situations. Once closed, the hooks overlap to form a continuous body.

Split shackles are popular in off-road recovery kits, trailering setups, and commercial towing, offering a combination of strength and convenience. While not as common as screw pin or soft shackles, they’re valued for reducing rigging time and allowing connections where traditional shackles might be too cumbersome to use or install.

Stainless Steel Shackles

Stainless Steel Bolt Anchor Shackle

Stainless steel shackles are built for environments where corrosion resistance is essential—marine, food-grade, pharmaceutical, and chemical industries. They’re available in bow or D styles and often used in architectural applications where both strength and appearance matter. Stainless steel holds up better than galvanized steel in saltwater, but it's generally more expensive and slightly less strong in high-load scenarios.

Since stainless steel shackles resist corrosion well, this makes them good for wet or coastal off-roading. However, when it comes to show rigs and color matching, they come in limited colors, mostly silver or polished, which limits customization. They are also generally less strong than forged steel shackles, so not ideal for heavy recovery work.

Decorative Shackles

Show Truck Decorative Shackle

Decorative shackles are primarily designed for looks rather than function. Commonly found on show vehicles, motorcycles, or even trailers, these shackles are available in a range of eye-catching finishes such as polished chrome, anodized aluminum, or brightly colored coatings. Their eye-catching appearance and unique designs often make them a popular choice for those looking to add a visual accent to bumpers, hitches, or tie-down points. While they may resemble standard bow or D-ring shackles, their purpose is aesthetic—not structural.

Most are made from aluminum using light machining or casting—processes that prioritize shape and finish over strength. Casting, in particular, involves pouring molten metal into molds, which creates smooth surfaces but lacks the internal grain alignment found in forged shackles. This makes decorative shackles structurally weaker in comparison. Additionally, their sharp edges and narrow bearing surfaces can damage soft shackles, straps, or kinetic recovery ropes. Due to these compromises in both strength and design, decorative shackles should only be used where looks matter—not where performance or safety is required.

Captive Pin Shackles

Retaining Snap Ring Shackle

Captive pin shackles, sometimes referred to as snap ring or crossbeam shackles, use retaining rings to secure the pin, making them a type of round pin shackle. The smooth, non-threaded pin is held in place by a snap ring that may fit into a groove inside the shackle body’s pin hole or, sometimes, in a groove on the pin itself. This snap ring locks the pin in place to prevent it from backing out during use, providing a clean, low-profile retention method ideal for compact assemblies.

However, removing and reinstalling snap rings requires the proper tools, which can be cumbersome to find, carry and use in off-road or recovery situations. Additionally, due to their spring tension, snap rings can easily fly off and get lost during removal or deployment, especially out on the trail, making them frustrating and unreliable when quick or repeated access to the shackle pin is needed. Because of this, snap ring shackles are generally less favored for critical recovery tasks where durability and ease of use are paramount.

Synthetic Sling Shackles

synthetic sling webbing shackle

Synthetic sling shackles are designed with smooth, wide bows and a flat bearing surface to perfectly match the shape of soft rigging like synthetic round slings or web slings. This extra surface area helps reduce pinching, wear, and deformation of the sling material, extending its service life. These shackles are ideal for delicate loads, theatrical applications, or anywhere synthetic rigging is preferred due to weight or surface concerns. Some are specially coated or designed to match the bend radius of common webbing sizes.

While synthetic sling shackles offer excellent protection for soft rigging and delicate materials, they are generally not well-suited for off-road vehicle recovery. Their large, smooth bows are optimized for wide synthetic sling, not for fitting into tight recovery points, mounts, or closed tow loops commonly found on off-road bumpers. Additionally, they lack the compact strength and durability of forged steel shackles, making them vulnerable in the high-impact, angled, or unpredictable pulls typical in off-road scenarios. For vehicle recovery, more robust options like screw pin, bow shackles or split shackles are usually a better fit.

Wide Body Shackles

Crosby Wide Body Shackle

Wide body shackles are oversized versions of bow shackles, built specifically to increase the surface area of the connection. This design helps extend the life of synthetic rigging and webbing slings by reducing stress concentrations and minimizing bend radius. They’re frequently used in high-capacity lifts where synthetic slings are employed or where an especially large load-bearing area is required.

While wide body shackles protect synthetic slings and reduce wear, they’re not ideal for off-road vehicle recovery. Their large size often doesn’t fit typical recovery points, and despite their bulk, they usually can't match the load ratings of forged anchor screw pin shackles. For most off-road situations, anchor (bow) type shackles or even split shackles offer better strength, fit, and ease of use.

Long Reach Shackles

Long Reach Shackle

Long reach shackles feature an extended internal length to accommodate deeper or hard-to-reach attachment points. These are often used in construction rigging, crane lifting, and fabrication work where standard shackles won’t fit over wide or awkward anchor points. The extra length can reduce the need for additional rigging components, but these shackles must be selected carefully to avoid introducing side load.

Long reach shackles are generally not recommended for off-road vehicle recovery due to their extended body design, which can introduce unintended side loading, something that must be avoided in recovery scenarios. Their long shape also reduces overall strength compared to standard anchor shackles of the same diameter, making them less reliable under dynamic or shock loads common in off-road pulls. Additionally, their size often doesn't align well with typical vehicle recovery points, making fitment and safety an issue.

Sheet Pile Shackles

Sheet Plie Shackle

Sheet pile shackles are a specialized type designed for driving or lifting steel sheet piles, which are long, interlocking sections of steel used to form continuous barriers in soil. Sheet piles act as retaining walls and are commonly used in marine construction, seawalls, cofferdams, and excavation support. These shackles feature a unique shape tailored to the interlock geometry of specific sheet pile profiles, ensuring a snug and secure fit. Engineered to endure the high, repetitive shock loads generated by pile-driving equipment, sheet pile shackles must be carefully matched to the exact sheet pile design to maintain safety and structural integrity during driving or extraction.

Theatrical Shackles

Theatrical Screw Pin Anchor Shackle

Theatrical shackles are purpose-built for the entertainment and staging industries, where visibility and appearance are just as important as strength. Typically finished in a flat black powder coat, these shackles are designed to blend in with lighting trusses, curtains, and rigging equipment to avoid drawing attention under stage lights. Despite their stealthy appearance, theatrical shackles are still rated for structural loads and meet the same safety standards as their industrial counterparts. They’re commonly used in concert production, theater rigging, film sets, and exhibition builds—anywhere that safety must be balanced with discretion and visual cleanliness.

They might be great for hanging lights and curtains in a theater, but unless you’re planning to hang your vehicle from the rafters, theatrical shackles aren’t really built for off-roading. Their flat black finish just helps them hide in the shadows on the trail at night.

Grab Shackles

Grab Flush Pin Shackle

Grab shackles are a type of D-shaped shackle, closely resembling standard chain or D shackles, but with a key difference: the pin head is countersunk so it sits flush with the shackle body. This streamlined, low-profile design allows the shackle to pass through tight circular openings, making it ideal for use in applications where clearance is limited. They are frequently used alongside grab hooks or chain adjusters, where the shackle needs to fit through a narrow slot or aperture without obstruction. This makes them especially useful in load securement systems, towing setups, or chain tensioning applications where standard pin heads might interfere with hardware or fail to fit. Despite their compact form, grab shackles maintain the strength and reliability of traditional D shackles, offering a precise fit and durable performance in demanding environments.

Twist Shackles

90 Degree Twist Screw Pin Shackle

Twist shackles are engineered with a 90-degree twist in the body so that the bow and the pin lie in perpendicular planes. This unique geometry allows them to connect components that are misaligned or oriented at different angles, such as a horizontal sling to a vertical eye. Twist shackles are especially useful in rigging scenarios where conventional shackles would introduce torque or side loading due to misalignment. Though they serve a very specific purpose, twist shackles should still be selected with the same care as standard rigging hardware, ensuring the working load limit is appropriate and the connection is properly aligned under load.

Soft Shackles

Soft Shackle

Soft shackles are made from synthetic rope—usually HMPE (High Modulus Polyethylene), such as Dyneema®. These ultra-strong, lightweight shackles have no metal components and are commonly used in off-road recovery, boating, and aerospace. They’re especially valuable where weight matters or where metal could damage sensitive equipment. Despite their light weight, soft shackles can match or exceed the working load limits of steel shackles when used correctly. However, they do require more care in handling and protection from sharp edges or abrasion.

Made from synthetic fibers, these shackles have a limited service life compared to metal ones. Exposure to UV rays, extreme temperatures, and chemicals can degrade the fibers over time, reducing their strength and durability. To ensure reliability during off-road recovery and other demanding uses, they require careful handling, proper storage, and regular inspection.

Tools Used to Tighten Screw Pin and Bolt-Type Shackles

Proper tightening of shackle pins is essential for safety and reliability in lifting and rigging applications. Different shackle types require different tools, or sometimes no tools at all, to secure the pin properly.

Screw Pin Shackles

Spud Wrench for Screw Pin Anchor and Bow Shackles

Screw pin shackles are designed for quick and easy hand tightening. The threaded pin can be turned and secured by hand without the need for special tools, making them ideal for temporary or frequently adjusted connections. However, in heavy-duty or industrial settings, a spud wrench is often used to provide additional torque and ensure the pin is fully tightened. A spud wrench features a tapered "spud" end for aligning holes and a wrench end that fits the pin head, making it a versatile rigging tool. While pliers or adjustable wrenches can sometimes be used in a pinch, they are not recommended as they risk damaging the pin surface.

Bolt-Type Shackles

Tools for bolt-type shackles

Bolt-type shackles require more secure fastening, especially in permanent or semi-permanent applications. These shackles use a threaded pin secured with a nut and cotter pin. To tighten the nut properly, common tools include open-end wrenches, box-end wrenches, or socket wrenches sized to fit the nut. Using the right size wrench ensures the nut is fastened to the correct torque without damaging the hardware. The cotter pin is then inserted through the nut’s hole and bent with a pair of pliers to lock it in place, preventing accidental loosening under vibration or dynamic loading.

Keeping Things Tight on the Trail

Once you've selected the right shackle for your off-road recovery setup, the next step is making sure it stays secure under stress or vibration. A loose or backing-out pin is one of the most common cause of lost gear, failure points in recovery gear and it can turn a routine pull into a gear-scattering disaster. Luckily, there are several proven methods to keep your shackle pin locked in place, whether you're crawling over rocks, slogging through mud, or hammering down a washboard trail. From traditional mousing techniques to modern thread-locking compounds, here’s how to make sure your rigging stays tight when it matters most.

Mousing

Mousing a recovery shackle with seizing wire to secure pin

Mousing a shackle might sound like you're out hunting rodents on the trail, but it actually refers to a technique used to secure the pin and prevent it from loosening or backing out during use. This is also sometime referred to as "seizing a shackle" and is especially important in applications exposed to vibration, movement, or shock loads—such as vehicle recovery, towing, or off-road driving. Without mousing, a screw pin shackle can gradually unthread itself, potentially leading to a dangerous disconnect under load.

The traditional method involves using safety wire. A length of stainless or galvanized wire is threaded through the hole in the shackle pin head and then wrapped tightly around the body of the shackle, securing the pin in place. This creates a physical lock that resists loosening, even under extreme conditions. It’s a tried-and-true technique favored in marine, industrial, and aerospace applications where safety is non-negotiable.

Mousing a offroad shackle pin with a zip tie

In the off-road world, however, the most common and practical method is using a heavy-duty zip tie. While not as secure as steel wire, a properly installed zip tie offers a fast, tool-free solution that’s good enough for most trail situations. It's widely used because it's quick, disposable, and easy to replace in the field. Still, it's important to check regularly, as zip ties can degrade in sunlight or break under stress—making it a convenient but temporary solution. Please be responsible and don't leave your zip ties out on the trail, they are harmful to the environment and are a danger to the surrounding wildlife.

Thread Locker

Blue Thread Locker for Recovery Shackles

Another method for securing the pin of a screw pin shackle is by using thread locker. Thread locker, often referred to as Loctite®, is a liquid adhesive—usually anaerobic—that's applied to the threaded portion of the pin to prevent it from loosening due to vibration, movement, or repeated shock loads. Once applied and the pin is tightened, the compound cures in the absence of air and creates a bond that helps hold the threads in place. This makes it especially useful in off-road applications, where vehicles often face uneven terrain and constant shaking that can cause unsecured pins to back out.

There are several types of thread locker, ranging from low strength (removable) to high strength (permanent). For shackle pins, a medium-strength (often purple, orange or blue-colored) thread locker is typically the best choice. It provides enough hold to prevent accidental loosening under normal use but can still be removed with hand tools when needed. High-strength variants (usually red) are generally too strong for regular maintenance and can make removing the pin very difficult without heat which can damage shackle and bumper coatings.

Using Plumber's Dope or Thread Compound for Shackle Pin

There’s also a budget-friendly alternative called plumber’s dope, also known as pipe thread compound. Unlike anaerobic thread lockers, this compound is aerobic allowing it to air dry. It remains soft and pliable after application and doesn't require the absence of air to set. While it's originally intended to seal threaded plumbing connections, it provides just enough tack to prevent a shackle pin from vibrating loose—without locking it permanently. Plumber’s dope is especially handy for those who frequently remove or reconfigure their recovery gear, as it allows for easy removal without heat or special tools. It’s also water-resistant, dirt cheap, and available at nearly any hardware store, making it a practical and accessible choice for trail repairs or last-minute setups. Just a little dab on your pin threads and you are pin stays put.

Shackle Pin Lanyards

B'oh Spin Pin Shackle 3/4 (White) Close Up

While shackle pin lanyards aren’t designed to keep your pin tight under load, they are an excellent solution for preventing lost pins in the field. By tethering the pin to the shackle body, these simple accessories ensure that if the pin backs out or is removed, it doesn’t disappear into the mud, sand, or trail brush. Typically made from coated cable, small chain, or heavy-duty cord, lanyards are a smart upgrade for off-roaders, construction crews, and stage riggers alike—anyone working in environments where dropped gear can cause injury or quickly becomes lost gear. They won’t stop loosening, but they’ll definitely stop the frustration of a missing pin when you need it most.

That said, traditional lanyards can be a pain. When you’re trying to fully remove a shackle pin, the lanyard often gets twisted or tangled, slowing you down—especially in tight spaces or urgent recovery situations. At Moose Knuckle Offroad, our Spin Pin System solves this issue with a built-in ring and groove design that allows the pin to rotate independently of the lanyard. This also leaves the pin head hole open for spud wrenches and other tools which means smooth, tangle-free operation without sacrificing the security of a tethered pin. It’s a smarter, trail-ready solution designed to keep your hardware—and your patience—intact.

Preferred Method of Tightening Screw Pin Shackles: New ASME Standard vs. Old Hand-Tight Practice

Traditional Hand-Tight Backing Off Method

Historically, screw pin shackles were commonly installed using the backing off method, a traditional technique where the pin was first fully tightened by hand, then slightly loosened by about 1/8 to 1/4 turn. This was done intentionally to relieve pressure on the threads and prevent the pin from binding under load.

The idea was to strike a balance:

  • Tight enough that the pin stays in place during use,
  • Loose enough that it doesn’t seize up and become difficult to remove afterward.

This method was particularly popular in:

  • Off-road recovery
  • Construction rigging
  • Maritime and field applications

While convenient and quick, the hand-tight backing off method had it's pros and cons:

Pros

  • Preventing Thread Bind or Galling: When a screw pin shackle is heavily loaded, especially under dynamic or shock loading, the pin can become extremely tight due to pressure and micro-friction on the threads. By slightly loosening the pin (usually 1/8 to 1/4 turn), users tried to avoid the threads “locking up” or galling, which made the shackle difficult or impossible to open later without tools or damage.
  • Thermal Expansion or Deformation: In applications where temperature changes or high loads were expected, backing off the pin gave the threads room to expand or move slightly without distorting or jamming.
  • Ease of Removal in the Field: Especially in field operations like off-road recovery or job-site rigging, where time and tools may be limited, a pin that could be removed by hand was preferable. Backing it off slightly helped ensure the shackle would be reusable after the pull or lift.

Cons:

  • Risk of Loosening: Vibration or dynamic loads can cause the pin to back out over time, leading to unsafe conditions.
  • Inconsistent Torque: Without a defined torque, some pins might be under-tightened, risking accidental opening, or over-tightened, which can damage threads.
  • No Verification: There’s no standardized way to verify if the pin is properly secured.

New ASME Standard (ASME B30.26) Guidance

The latest ASME B30.26 standard on rigging hardware updates the instructions for screw pin shackles to improve safety and reliability. It recommends:

  • Hand Tightening Followed by Additional Turn: After threading the pin hand tight, an additional partial turn (typically about a quarter turn) is applied using a tool (such as a spud wrench) to ensure the pin is securely seated without over-tightening.
  • Use of Torque Wrench or Defined Torque: Where possible, tightening to a specified torque value is preferred to ensure consistent and repeatable installation, especially for critical lifting applications. While torque values can vary by shackle size and manufacturer, referencing these specs improves safety.
  • Inspection and Re-Tightening: Regular inspection of shackles in use is required, and any signs of loosening must be addressed immediately.

Why the Change?

The updated method resolves the key risks of the older approach:

  • Improved Connection Security: A tighter fit resists vibration and shock loading.
  • Minimized Thread Damage: Controlled tightening prevents overtightening while still securing the pin.
  • Standardization Across Users: Torque specs and tool use help ensure repeatable, verifiable installation practices.

Materials Used to Make Shackles

The performance of a shackle is closely tied to the material from which it’s made. Most industrial shackles are made from carbon steel, which offers an excellent balance of strength and affordability. For more demanding applications, alloy steel is used due to its superior mechanical properties and higher working load limits. Stainless steel, as mentioned earlier, adds corrosion resistance but generally sacrifices a bit of raw strength.

Aluminum shackles, while not suited for high-capacity lifting, have gained popularity in industries such as motorsports and aviation, where reducing weight may be a priority. But often are not ideal for off-roading due to their lower safety factors and load ratings. Typically machined from high-strength aluminum alloys, they offer excellent corrosion resistance and are prized for their lightweight construction. However, due to aluminum’s lower toughness and fatigue resistance compared to forged steel, these shackles are best reserved for non-critical or controlled-load applications. Beyond functional use, aluminum shackles are also favored for ornamental or display purposes—particularly in custom automotive and marine builds where aesthetics are more important than performance.

For lightweight applications like soft shackles, synthetic fibers such as HMPE, UHMW-PE, Dyneema® or Spectra® are used. These offer incredibly high tensile strength-to-weight ratios but need protection from heat, UV degradation, and abrasion.

Many shackles are also galvanized or powder-coated for corrosion protection, particularly those used in marine or outdoor environments. Some high-end models include coatings or finishes specifically designed to prevent thread galling, seize-up, or corrosion at the pin interface.

How Shackles Are Manufactured

Drop Die Forging Shackles

Most high-quality shackles are drop forged, a process that involves heating a steel billet and pressing it into shape using high-pressure dies. Drop forging aligns the grain structure of the metal with the shape of the part, significantly increasing strength and toughness. This is the industry standard for lifting and rigging shackles because it produces a dense, uniform, and fatigue-resistant product capable of handling dynamic and static loads safely.

Die Forged Lifting Shackle

Forged shackles are typically subjected to precise heat treatments to enhance hardness and durability without making them brittle. After forging, the excess metal is removed, they’re often machined to exact tolerances then inspected for defects using non-destructive testing methods such as magnetic particle inspection or ultrasonic testing. This level of quality control ensures that forged shackles meet strict standards making them suitable for critical applications like overhead lifting, recovery, and structural rigging. In short, if safety and reliability are top priorities, forged shackles are the only real option.

Lower-cost shackles may be cast, where molten metal is poured into molds. While casting allows for more complex shapes and lower production costs, it generally produces weaker parts than forging. Cast shackles are usually found in decorative or non-critical applications—not for lifting or load-bearing.

A third, less common process is machining from billet stock, used for custom or specialty shackles. This offers precision and consistency but is time-consuming and expensive.

When selecting shackles for lifting, recovery, or structural use, always look for markings indicating WLL (Working Load Limit), grade, and certification standards such as ASME B30.26, ASTM A148, EN 13889 or CE.

Final Thoughts

From rugged steel shackles built for industrial cranes to lightweight soft shackles made for modern 4x4 recovery, there’s a purpose-built option for every scenario. When it comes to vehicle recovery, off-roading, and overlanding, screw pin anchor shackles, split shackles, and soft shackles are by far the most reliable and widely trusted choices. These shackles combine strength, ease of use, and versatility—making them the go-to hardware for tough, real-world recovery situations. Choosing the right shackle isn’t just about convenience; it’s about safety, performance, and ensuring your gear won’t let you down when it matters most. A properly matched shackle doesn’t just hold your rigging—it holds your entire operation together.

At Moose Knuckle Offroad, we offer premium-grade shackles engineered for performance, tested for reliability, and designed for real-world abuse. Whether you're outfitting your vehicle build, assembling a recovery kit, equipping your trailer, or managing off-road or overlanding recoveries, we’ve got the perfect shackle for the job.
